Disc Type 60L Sand Mill Bead Mill Machine For Soluble Concentrate Production

  • 1
  • 2

Brand Name : DEGOLD

Model Number : ZM60SB3310-E

Certification : CE

Place of Origin : Chongqing China

MOQ : 1 SET

Price : US $15,000.00-30,000.00

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30 SET MOUTHS

Delivery Time : 5-8 work days

Packaging Details : Non fumigation wood packaging

Grinding chamber volume : 60L

Main motor power : 37KW

Inner grinding chamber material : SKD11

Grinding discs material : SKD11

Raw materials transfer pump : Ingersoll Rand

Linear velocity : 11M-12M/S

explosion-proof : Overall explosion-proof equipment

Contact Now

60L High-Efficiency Disc-Type Sand Mill Bead Mill Machine Soluble Concentrate Production Equipment

Usage Scenarios:

  • Chemical industry: Used for grinding, mixing, dispersing, and homogenizing particles.
  • Coating, paint, ink industry: Used for grinding and dispersing pigments to improve color uniformity and fineness.
  • Food industry: Used for fine grinding, dispersing, and homogenizing food particles.
  • Pharmaceutical industry: Used for grinding, mixing, and dispersing pharmaceutical particles to improve solubility and bioavailability.

Principle of Operation:
The rotary grinding shaft drives all grinding media inside the grinding chamber. The grinding media pass the power to the materials, reducing their particle size. The gap separator inside the horizontal bead mills separates the products and the grinding media. Bead grinders are suitable for different viscosity formulations.

Usage Method:

  • Preparation: Ensure that the equipment and grinding media are in good condition and that the equipment is clean.
  • Adjust parameters: Adjust the speed of the disc-type sand mill, the quantity and size of the grinding media, and the grinding time based on the properties and requirements of the materials.
  • Feeding and operation: Add the materials to be ground along with the grinding media into the grinding chamber and start the equipment for grinding. Additional additives or adjustments in temperature can be gradually added as needed.
  • Monitoring and adjustment: Monitor the grinding effect and the state of the materials during the grinding process. Stop the equipment and check the particle size and dispersion effect of the materials if necessary, and make necessary adjustments.
  • Cleaning and maintenance: Clean the equipment promptly after grinding, removing any residue materials and grinding media. Perform regular maintenance and upkeep of the equipment to ensure its normal operation and longevity.

Technical Data:

ZM-E Series ZM20-E ZM60-E ZM100-E ZM200-E ZM300-E ZM500-E ZM1000-E
Grinding chamber volume (l) 20 60 100 200 300 500 1000
Batch size (l) 100-500 200-1000 500-2500 1000-10000 >2000
Drive (kW) 18.5-22 37-45 55-75 75-90 90-110 160-200 315
Grinding shaft rotary speed (r/min) 1200 800 650 500 460 350 340
Length (mm) 1670 1970 2750 2950 3450 3350 6650
Width (mm) 1050 1150 1200 1200 1300 1500 1450
Height (mm) 1565 2000 2200 2200 2250 2700 2850
Net weight (kg) 750 1500 3500 3700 4700 8000 12000
Ex proof Type Ex proof / Non Ex proof
Seal Type Single Mechanical Seal / Double Mechanical Seal
Inner Grinding Cylinder Material SS304 / Hard Steel / Mold Steel / Tungsten Carbide / Ceramic / PU
Grinding Disc Material SS304 / Hard Steel / Mold Steel / Tungsten Carbide / Ceramic / PU
Pump Type Diaphragm pump / Gear Pump / Screw pump
Mill Speed Adjustment Way With inverter / Without inverter
Note: Technical data are different if there are some customized constructions.
We'd like to send you the suitable model sand mills for your production, please feel free to contact with us.

Disc Type 60L Sand Mill Bead Mill Machine For Soluble Concentrate Production

Disc Type 60L Sand Mill Bead Mill Machine For Soluble Concentrate Production

The disc-type ball mill can achieve grinding and milling within a particle size range that depends on several factors, including the design of the disc-type ball mill, operating parameters, and material characteristics. Generally, the disc-type ball mill can achieve the following particle size ranges:

1,Coarse grinding stage: During the coarse grinding stage, the disc-type ball mill can grind materials to larger particle sizes, typically ranging from millimeters to hundreds of micrometers.

2,Intermediate grinding stage: In the intermediate grinding stage, the disc-type ball mill further refines the materials to achieve particle sizes ranging from hundreds of micrometers to tens of micrometers.

3,Fine grinding stage: During the fine grinding stage, the disc-type ball mill can grind materials to smaller particle sizes, typically ranging from tens of micrometers to a few micrometers.
